 Topic: Show us your Distro..Posted: 30 September 2013 at 3:28pm |
|
63A In. single phase. 2 x 32A, 2 x 16A, 4 x 13A Outs
Blue Rack - 32A 3Phase In, Originally with Schuko's, But changed to 16A Ceeform Outs.
|
|
 |
|
|
ruelectrical
Registered User
Joined: 03 February 2011 Location: Gloucester Status: Offline Points: 269 |
Post Options
Thanks(0)
Quote Reply
Posted: 30 September 2013 at 7:08pm |
|
I recognise the 63 amp distro, glad its been put to good use, PAT labelling is a bit out of date !!!
|
|
|
|
|
razorray
Registered User
Joined: 06 December 2005 Location: London Status: Offline Points: 425 |
Post Options
Thanks(0)
Quote Reply
Posted: 01 October 2013 at 7:33pm |
|
|
|
|
|
|
James Tengo
Old Croc
Joined: 09 May 2008 Location: Brighton Status: Online Points: 2155 |
Post Options
Thanks(0)
Quote Reply
Posted: 05 October 2013 at 6:44pm |
|
Bit quiet in here so I thought I'd join with a compact system I'm currently touring
This is a Coloursound BT Distro, based loosely on their S type distro, but with individual RCOB's per outlet, designed to run their LED walls (BT = Big telly, their video walls are all named BTx, where x is the pixel pitch) 63a 3ph input, 32a 3ph outlet (motors usually, dimmer in this application) 3x 16a 1ph outlets (control usually) and 3x socca outs.  Rear shot  Chamsys at FOH  And a bit of desk porn for the rest of you, H2000 house desk, Pro6 touring desk, supplied by BritRow  Walk in state, Ancienne Belgique in Brussels, one of my favourite venues in Europe  |
|
|
|
|
GAZ.
Old Croc
Joined: 16 January 2007 Location: Hertfordshire Status: Offline Points: 2433 |
Post Options
Thanks(0)
Quote Reply
Posted: 05 October 2013 at 7:45pm |
|
I've got 4 EMO distros, 3 with 8 13a sockets on and 1 with 4. All now converted to powercon inputs and used in racks
 .  I've also got 2 kelsey's 1x PD7/32 [old type with 3 sockets on the front, newer ones only have 1] ]  And a PD7/16, Same as above but 16a input and link for those that dont know! And a Rubber Box RUB1409C
|
|
|
100% Earth Moving Bass
|
|
|
|
|
James Tengo
Old Croc
Joined: 09 May 2008 Location: Brighton Status: Online Points: 2155 |
Post Options
Thanks(0)
Quote Reply
Posted: 05 October 2013 at 9:13pm |
|
An old shot here, from Soulwaxmass 2011, dimmer beach, consists of a D type distro (known as the daddy distro, which is 400a powerlock in and thru, 1x 63a 3ph out, 2x 32a 3ph outlets, 12x socca outlets, 6x 16a 1ph outlets, 3x 32a 1ph outlets and 2x 13a outlets) an L type distro (L for leftfield, originally made to run a lot of diversitronics strobes, pre martin atomic, each needed a 32a 1ph feed, so it has powerlock in and thru, and 9x 32a 1ph outlests, 3x soccas and 2x 32a 3ph outlets) a BT distro, and an avolites art 2000 dimmer, (48ch) and two strand act 3 (5kw/ch) dimmers. In the background is motor control world
|
|
|
|
|
Adam_Iron_Horse
Old Croc
Joined: 02 January 2010 Location: Scotland Status: Offline Points: 2043 |
Post Options
Thanks(0)
Quote Reply
Posted: 05 October 2013 at 9:18pm |
|
Custom built by a forum member
3 20A rings with 2 Powercon on each 1 10A ring with 2 IECs 1 5A ring with 2 IECs 1 16A ring with powercon on the front
|
|
|
|
|
razorray
Registered User
Joined: 06 December 2005 Location: London Status: Offline Points: 425 |
Post Options
Thanks(0)
Quote Reply
Posted: 09 October 2013 at 10:24am |
|
Continuing with my distro fetish. 14 x 16 AMP Outs 3 x 32 AMP Outs 1 x 13 AMP Out.
|
|
|
|
|
AM55
Old Croc
Joined: 16 August 2007 Location: Matlock Status: Offline Points: 1728 |
Post Options
Thanks(0)
Quote Reply
Posted: 09 October 2013 at 10:51am |
Where does the sprung loaded cap on a socket go when connected to the two inputs? Edited by AM55 - 09 October 2013 at 10:52am |
|
|
|
|
razorray
Registered User
Joined: 06 December 2005 Location: London Status: Offline Points: 425 |
Post Options
Thanks(0)
Quote Reply
Posted: 09 October 2013 at 11:25am |
|
remove sprung cap from plug
|
|
|
|
|
adyk
Registered User
Joined: 05 May 2009 Status: Offline Points: 442 |
Post Options
Thanks(0)
Quote Reply
Posted: 09 October 2013 at 1:32pm |
  Edited by adyk - 09 October 2013 at 1:34pm |
|
|
|
|
QSS
Old Croc
Joined: 21 July 2009 Location: Bristol UK Status: Offline Points: 2414 |
Post Options
Thanks(0)
Quote Reply
Posted: 30 October 2013 at 7:38pm |
 |
|
|
"Music is life"
|
|
|
|
|
